Corby Bolt - Aluminum - SMALL .140" shaft .187" shoulder *NEW SHAFT LENGTH

In stock
Shelf Location
Bulk Discounts
  • Buy 4 for $1.88 each and save 2%
  • Buy 10 for $1.80 each and save 6%
  • Buy 25 for $1.73 each and save 10%
  • Buy 50 for $1.65 each and save 14%
  • Buy 100 for $1.59 each and save 17%
Write Your Own Review
You're reviewing:Corby Bolt - Aluminum - SMALL .140" shaft .187" shoulder *NEW SHAFT LENGTH
Your Rating

Corby Style Bolts

  • .140" Shaft .235" long shaft

  • .187" Shoulder .230" long shoulders

  • .240" long thread

  • Over all length is 1", OAL max length is 1.15"

  • Aluminum - Super light for when every bit of weight matters

  • both ends slotted

  • Use these Corby style bolts to connect handles to a knife tang. For a full tang knife:

    • You drill a hole in the tang the size of the shaft. Then you drill holes part way through the handle material the diameter of the shoulder.

  • For a hidden tang knife:

    • Dry mount your handle to the hidden tang so it doesn't move. Drill a hole through both handle and tang in one pass. Then drill the handle material partially to depth the diameter of the shoulder.

  • Screw the two parts together fastening the scales to the tang. The ends of the bolts are slotted so you can use a screw driver on both ends to tighten the bolt. When you have it tight, you grind off the excess bolt material leaving a nice pin showing. You can also grind the shaft and/or threads to shorten them up. The shoulder and shaft are almost certainly longer than the thickest handle/tang combination.

  • We have these custom made exclusively for us.

NOTE: These are sold in single bolts. You will probably need to order 2 of these for a typical knife handle. You are ordering one each as shown above in the description.
